AVM-156MF
Display module AVM-156MF is designed for displaying of graphic information coming via LVDS interface or DVI-D (1920x1080), 60 Hz. High brightness and screen resolution provide precise data readout.
Complete set of goods
Product Documentation
| Param name | Param value |
| Display | 39 cm, (15,6″) |
| Brightness (cd/m) | 1000 |
| Contrast | 500:1 |
| Viewing angle (°) Н/V horizontal vertical | +/-80 +/-65/80 |
| Resolution | 1920x1080 |
| Interface | LVDS 6 / 8 bit DVI-D |
| Power supply (V) | +12;27 |
| Power consumption (W) | 50 |
| Weight (kg) | 4 |
| Dimensions: width/height/depth (mm) | 370/240/39 |
| Temperature (°С) work short-term working (0,5 h) highest | -55...+55 +70 -60...+85 |
| Humidity (%) | 98%, 35°С |
| Vibration | 10...2000Hz,1,8g |
| Shocks (g) single frequentative | 15 6 |
